Description
It has the characteristics of seamless display, long service lifespan, high frame rate, high refresh rate, good uniformity, wide viewing angle, high grayscale, natural color reproduction, etc. It is widely used in command and dispatch, security monitoring, video conference, television studio, various indoor conference rooms, etc.
Feature of C series-Y5 Economical Indoor LED Screen
- Used to monitor and display the scene situation in real-time and play various
- Seamless splicing, no visual black seams.
- The display unit is flexible and compact to achieve smooth flat and curved splicing.
- DC low-voltage power supply, natural heat dissipation, no fan, and zero noise.
- It only needs to maintain a single LED pixel or a single module when it fails, which is convenient and cost-saving.
| Model | C1.53 |
| LED encapsulation | SMD1212 black light |
| Pixel pitch | 1.53mm |
| Resolution | 422500 pixels/m² |
| Lamp bead/IC | NATIONSTAR copper wire/high fresh rate |
| Color configuration | 1R1G1B |
| Cabinet resolution | 416*312 |
| Cabinet size (mm) | 640*480 |
| Cabinet weight | 5kg/pc |
| Power voltage | DC+4.2V~+5V |
| Main parameter | |
| Best viewing distance | ≥4.6m |
| Horizontal viewing angle | ≥175° |
| Vertical viewing angle | ≥175° |
| Maintenance method | Front maintenance |
| Graphics card | DVI/HDMI/DP |
| Video signal | Compatible with PAL/NTSC/SECAM format, support S-Video; VGA; RGB; CompositeVideo; SDI; DVI; RF; RGBHV; YUV; YC, etc. |
| Control mode | Synchronous control |
| Drive device | Constant current |
| Refresh rate | ≥3840Hz |
| Frame rate | ≥60Hz |
| Scanning method | 52S |
| Brightness | 200～600CD/m² |
| Grayscale | 12/14/16bit |
| Contrast | ≥10000:1 |
| Attenuation rate (after 3-year work) | ≤15% |
| Brightness adjustment | Auto/Manual: 1～100% |
| Computer operating system | WIN98/2000/WINXP/WINVista/WIN7 |
| MTBF | ≥20000H |
| Lifespan | ≥100000H |
| Failed rate | ≤1/100000 and no continuous failed pixels |
| Software | Professional LED display system programming software |
| Storage temperature | -35℃～+85℃ |
| Working temperature | -20℃～+60℃ |
| Working voltage (AC) | 220V±10%/50Hz or 110V±10%/60Hz |
| Average power consumption | ≤168W/m² |
| Maximum power consumption | ≤500W/m² |
| Installation method | Die-cast aluminum cabinet |
| Brightness uniformity | ≥99% |
| Protection class | IP5X |
